How to fit a jaw crusher flywheel?

Fitting a jaw crusher flywheel involves several important steps to ensure proper installation and function. Here's a general guide to help you undertake this process safely and effectively:

Tools and Materials Needed:

  • Jaw crusher flywheel
  • Wrenches or spanners
  • Torque wrench
  • Lifting equipment (hoist or crane)
  • Thread locker (if recommended by manufacturer)
  • Safety gear (gloves, helmets, safety glasses)

Steps to Fit a Jaw Crusher Flywheel:

  1. Safety First:

    • Turn off and isolate power: Ensure the jaw crusher is completely de-energized before starting any work.
    • Safety gear: Wear appropriate personal protective equipment (PPE).
  2. Prepare the Flywheel:

    • Inspect the new flywheel for any defects or damages.
    • Clean the mounting surface on the flywheel and the shaft where it will be attached.
  3. Align the Flywheel:

    • Position the flywheel close to the mounting area using lifting equipment, ensuring it is properly aligned with the shaft.
    • Take care to avoid damaging the shaft, keyway, or the flywheel bore during this process.
  4. Mount the Flywheel:

    • Gradually slide the flywheel into position over the shaft. If the flywheel uses a key, make sure it aligns with the keyway on the shaft.
    • Push the flywheel onto the shaft firmly. It might require gentle tapping with a mallet to sit flush with the shoulder of the shaft.
  5. Securing the Flywheel:

    • Fasten the flywheel in position using the appropriate bolts or nuts. Refer to the crusher's manual for the correct specification and torque settings.
    • Tighten bolts in a crisscross pattern to ensure even distribution of pressure.
  6. Torquing the Bolts:

    • Use a torque wrench to torque the bolts to the manufacturer's specified settings. This is crucial to prevent over-tightening or under-tightening, which can cause operational issues.
  7. Apply Thread Locker:

    • If recommended by the manufacturer, apply thread locker to the bolts before tightening to prevent them from loosening due to vibration.
  8. Final Checks:

    • Double-check that all bolts are torqued correctly.
    • Rotate the flywheel by hand to ensure it moves freely without any obstruction or binding.
  9. Re-energize and Test:

    • Once confident the flywheel is secure and properly installed, restore power to the jaw crusher.
    • Perform a test run to make sure everything operates smoothly and listen for any unusual noises.

Tips:

  • Consult the Manual: Always refer to the crusher manufacturer’s manual for model-specific instructions and safety guidelines.
  • Use Proper Tools: Always use tools that are suitable for the job to avoid damaging components.

By following these steps and ensuring all procedures are carried out correctly, you can fit a jaw crusher flywheel safely and ensure your crusher operates efficiently.
