A mobile sand washing plant is a versatile piece of equipment used to cleanse and process sand or gravel, removing unwanted materials to produce a clean, high-quality end product. Here's a general overview of how such a plant typically works:
-
Feeding and Screening:
- Feed Hopper: The sand or gravel is loaded into a feed hopper. A conveyor or a feeder transfers the material to the washing unit.
- Screening: The material is then conveyed to a screening deck where oversized materials (larger aggregates suitable for other uses) are separated from fine sand and unwanted debris. This can involve a series of vibrating screens that sort particles by size.
-
Washing:
- Washing System: The heart of the plant is the washing system, which usually involves a combination of a sand screw, hydrocyclones, and/or a collection tank with a pump system.
- Sand Screws/Spirals: Sand screws or spirals treat the material by allowing finer particles to pass through while larger, unwanted materials are transported away and discarded or moved for further processing.
- Hydrocyclones: These devices use centrifugal force to separate finer particles and reduce the amount of water in the final product. They help classify sand and separate fines, such as silt and clay, into overflow and underflow streams.
-
Separation and Dewatering:
- Separation: In some setups, additional separation is performed using spiral classifiers or classifiers tanks, which separate the sand based on particle size and weight.
- Dewatering Screens: After washing, the sand passes over dewatering screens or is sent through a dewatering screw to remove moisture, leaving behind cleaner and drier sand.
-
Water Management:
- Water Recycling: A critical feature of most modern mobile sand washing plants is their ability to recycle water. The water used in washing is typically collected and passed through a water treatment system, separating out fines and other contaminants.
- Sedimentation Tanks: Settling tanks may be used to allow suspended solids to fall out of solution and for clarified water to be reused in the process.
- Flocculants: Chemicals known as flocculants can be added to help bind fine particles together, promoting faster settling in the water recycling system.
-
Final Product Conveyance and Disposal:
- Conveyance: Once sand is cleaned and dewatered, it is conveyed to storage or directly loaded onto a truck for transport.
- Waste Disposal: Byproducts like silt, clay, and other larger unwanted materials are either stockpiled for future use, processed further, or disposed of, depending on the material composition and regulatory requirements.
Mobile sand washing plants offer the advantage of being easily transportable, enabling operators to process materials directly at a site rather than move raw materials to a stationary processing location. This flexibility can reduce transportation costs and improve economic efficiency for construction or mining operations.
