How to determine the size of the conveyor belt in mining？

Determining the size of a conveyor belt for mining involves several steps and considerations. Here are the key factors to consider:

  1. Material Characteristics:

    • Type: Identify the material being transported (e.g., ore, coal, gravel).
    • Density: Measure the bulk density of the material.
    • Size and Shape: Consider the size, shape, and gradation of the material.

  2. Conveying Capacity:

    • Tonnage: Calculate the desired conveying capacity in tons per hour (TPH).
    • Belt Speed: Determine the appropriate belt speed, typically in meters per second (m/s).

  3. Belt Width:

    • Use industry standards or specific formulas to decide the belt width. Typically, wider belts are needed for higher capacities and larger material.

  4. Inclination Angle:

    • Account for the conveyor’s inclination as it can affect capacity and belt width.

  5. Idler Spacing and Load:

    • Determine the spacing of idlers (support rollers) based on the load, belt speed, and material properties.

  6. Environmental Factors:

    • Consider the operating environment, such as temperature, moisture, and potential exposure to chemicals or abrasive materials.

  7. Belt Length:

    • Measure the horizontal distance between the loading and discharge points.
    • Account for vertical lifts and drops.

  8. Drive Power:

    • Calculate the required drive power to support the desired belt speed and load.

  9. Regulatory Standards:

    • Ensure compliance with all relevant safety and operational standards and regulations in the mining industry.

Step-by-Step Calculation:

  1. Determine Material Flow Rate:

    • Use the formula ( Q = A \times V \times D )
    • Where ( Q ) is the throughput (TPH), ( A ) is the cross-sectional area of material on the belt (m²), ( V ) is the conveyor speed (m/s), and ( D ) is the material density (kg/m³).

  2. Calculate Belt Width:

    • Reference tables or conveyor manufacturer guides usually provide belt width recommendations based on material type and capacity.
    • Common rule of thumb: For granular material, the belt width is approximately 2-3 times the largest particle size.

  3. Verify with Conveyor Manufacturer:

    • Consult with conveyor system manufacturers for precise recommendations based on your specific mining application.

Example Calculation:

  1. Suppose you need to transport 500 TPH of ore with a bulk density of 1600 kg/m³.
  2. Assume a belt speed of 1.5 m/s.
  3. Using the formula, calculate the required cross-sectional area: ( Q = A \times V \times D \Rightarrow A = \frac{Q}{V \times D} = \frac{500,000 \, kg/h}{1.5 \, m/s \times 3600 \, s/h} \approx 0.092 \, m² )

Based on this area, select the corresponding belt width from standard sizing charts.

By following these considerations and steps, you can determine the appropriate size for your mining conveyor belt.
